Model Interpretation in Genomics

▶ Try in Colab

A major challenge with "Black Box" foundation models is trust. If a model predicts a SNP is pathogenic, a biologist needs to know why.

Saliency Maps

The most direct way to interpret a genomic model is to ask: "Which token positions contributed most to this prediction?"

The Method: Gradients w.r.t. Input Embeddings

We compute the gradient of the model's output with respect to the input embedding matrix. The L2 norm of the gradient at each position gives a saliency score:

\[ \text{Saliency}(i) = \left\| \frac{\partial \hat{y}}{\partial \mathbf{e}_i} \right\|_2 \]

A high score at position \(i\) means that small changes to that token's embedding would strongly affect the prediction.

saliency

Template Code: Gradient Saliency

import torch

model.eval()
sequence = test_ds[0]["ref_forward_sequence"]

# Tokenize the sequence
enc = tokenizer(sequence, return_tensors="pt", truncation=True, max_length=512).to(device)

# Step 1: Get input embeddings and enable gradient tracking
input_embeds = model.get_input_embeddings()(enc["input_ids"])  # (1, seq_len, dim)
input_embeds.requires_grad_(True)
input_embeds.retain_grad()

# Step 2: Forward pass using embeddings instead of token IDs
out = model(inputs_embeds=input_embeds,
            attention_mask=enc["attention_mask"],
            output_hidden_states=True)

# Step 3: Define target — sum of logits at the SNP token position
# (or use the classification logit for fine-tuned models)
snp_pos = 50000  # example SNP position in original sequence
snp_token_idx = snp_pos // 6 + 1  # 6-mer stride, +1 for CLS token
snp_token_idx = min(snp_token_idx, out.logits.shape[1] - 1)

target = out.logits[0, snp_token_idx].sum()
target.backward()

# Step 4: Saliency = L2 norm of gradient at each token position
saliency = input_embeds.grad[0].norm(dim=-1).detach().cpu().numpy()
# saliency.shape = (seq_len,)
print(f"Saliency shape: {saliency.shape}")
print(f"Peak saliency at token: {saliency.argmax()}, SNP token: {snp_token_idx}")

Template Code: Visualizing the Saliency Map

import matplotlib.pyplot as plt

plt.figure(figsize=(12, 4))
plt.plot(saliency, color="steelblue", linewidth=1.5, alpha=0.8)
plt.fill_between(range(len(saliency)), saliency, alpha=0.2, color="steelblue")
plt.axvline(snp_token_idx, color="red", linestyle="--", linewidth=2,
            label=f"SNP token ({snp_token_idx})")
plt.xlabel("Token Position")
plt.ylabel("Saliency (‖∇embedding‖₂)")
plt.title("Gradient Saliency Along Sequence")
plt.legend()
plt.tight_layout()
plt.show()

Linking to Science: Motif Discovery

When we visualize these saliency maps, we often see peaks at known regulatory motifs:

  • Peak at TATAAA → The model learned the TATA box (core promoter element).
  • Peak at GATA → The model learned a GATA transcription factor binding site.
  • Peak at the SNP position → The model directly links the variant to its functional impact.

If a SNP disrupts a saliency peak, it suggests the variant is breaking a transcription factor binding site.

Saliency Map Example (Visualization of importance scores. Source: DeepSEA, Nature Genetics 2015)

Interpretation Caveats

  • Gradient saliency is local: it measures sensitivity to infinitesimal changes at the current input, not the effect of the actual SNP mutation.
  • For more robust attribution, consider Integrated Gradients (averages gradients along a path from a baseline) or In Silico Mutagenesis (explicitly substitute each position and measure the change in output).

Attention Analysis

For Transformer models, we can also inspect the raw Attention Weights to see which parts of the sequence "attend" to each other.

Template Code: Extracting and Plotting Attention

import seaborn as sns

model.eval()
with torch.no_grad():
    out = model(**enc, output_attentions=True)

# Get the last layer's attention, averaged over all heads
# Shape: (n_heads, seq_len, seq_len)
last_attn = out.attentions[-1].squeeze(0).cpu().numpy()
avg_attn = last_attn.mean(axis=0)  # (seq_len, seq_len)

# Plot a window of tokens around the SNP
window = 10
start = max(0, snp_token_idx - window)
end   = min(avg_attn.shape[0], snp_token_idx + window)
attn_window = avg_attn[start:end, start:end]

fig, ax = plt.subplots(figsize=(8, 7))
sns.heatmap(attn_window, ax=ax, cmap="viridis", square=True)

# Highlight the SNP token row/column
snp_rel = snp_token_idx - start
ax.axhline(snp_rel, color="red", linewidth=2)
ax.axvline(snp_rel, color="red", linewidth=2)
ax.set_title("Attention Heatmap Around SNP (Last Layer, Head-Averaged)")
ax.set_xlabel("Key Token")
ax.set_ylabel("Query Token")
plt.tight_layout()
plt.show()
  • Biological Insight: Strong attention between a promoter region and a distant site may indicate an enhancer-promoter interaction.
  • Caution: High attention weight does not always imply causal importance. Use it as a guide for generating hypotheses, not as definitive evidence.

Pathway Analysis with Embeddings

We can also interpret the embeddings at a higher level by checking whether they cluster along known biological dimensions.

Workflow

  1. Extract embeddings for a set of SNPs (using extract_embeddings from the previous section).
  2. Reduce dimensions using PCA or UMAP.
  3. Color by biology: cell type, chromatin state, gene pathway.
from sklearn.decomposition import PCA

# delta = alt_embs - ref_embs  (each row is one SNP)
pca = PCA(n_components=2)
coords = pca.fit_transform(delta.numpy())

# Color by label (causal vs non-causal)
import matplotlib.pyplot as plt
for label, color, name in [(0, "steelblue", "Non-causal"), (1, "coral", "Causal")]:
    mask = y == label
    plt.scatter(coords[mask, 0], coords[mask, 1],
                c=color, alpha=0.4, s=10, label=name)
plt.xlabel(f"PC1 ({pca.explained_variance_ratio_[0]*100:.1f}%)")
plt.ylabel(f"PC2 ({pca.explained_variance_ratio_[1]*100:.1f}%)")
plt.title("PCA of Delta Embeddings (alt − ref)")
plt.legend()
plt.tight_layout()
plt.show()

If causal and non-causal SNPs separate in PCA space, the foundation model has learned something biologically meaningful about variant impact.
